Drive Axle for Forklifts

Drive Axle Forklift - The piece of machinery that is elastically fastened to the frame of the vehicle utilizing a lift mast is the forklift drive axle. The lift mast connects to the drive axle and could be inclined, by at least one tilting cylinder, around the drive axle's axial centerline. Forward bearing elements along with back bearing elements of a torque bearing system are responsible for fastening the vehicle and the drive axle frame. The drive axle can be pivoted around a swiveling axis oriented horizontally and transversely in the vicinity of the back bearing components. The lift mast is also capable of being inclined relative to the drive axle. The tilting cylinder is attached to the lift truck frame and the lift mast in an articulated fashion. This enables the tilting cylinder to be oriented almost parallel to a plane extending from the swiveling axis to the axial centerline.

Forklift models like H35, H40 and H45 which are made in Aschaffenburg, Germany by Linde AG, have the lift mast tilt ably mounted on the vehicle framework. The drive axle is elastically affixed to the lift truck frame utilizing many bearing tools. The drive axle contains a tubular axle body along with extension arms connected to it and extend backwards. This particular type of drive axle is elastically attached to the vehicle framework utilizing rear bearing elements on the extension arms together with frontward bearing devices located on the axle body. There are two back and two front bearing devices. Each one is separated in the transverse direction of the lift truck from the other bearing device in its respective pair.

The braking and drive torques of the drive axle are sustained through the rear bearing parts on the framework by the extension arms. The load and the lift mast create the forces that are transmitted into the road or floor by the frame of the vehicle through the drive axle's front bearing parts. It is essential to make certain the parts of the drive axle are installed in a rigid enough way to be able to maintain strength of the forklift truck. The bearing parts could lessen slight bumps or road surface irregularities all through travel to a limited extent and give a bit smoother function.
